Large GRP Storage Tanks

GRP vessels are fabricated on site by filament winding, jetting molding, contact molding, etc. using fiberglass and its products as the reinforcing materials and resin as the base material.

MOQ: No minimum order quantity

Price: Negotiable

Delivery Time: 20-25 days

Payment: TT, L/C

Supply Ability: 1000000 pcs/ month

Classification：

Oilfield Surface System

Whatsapp
Email
Inquiry

BACK

Description

GRP vessels are fabricated on site by filament winding, jetting molding, contact molding, etc. using fiberglass and its products as the reinforcing materials and resin as the base material.

◣ Scope of Production

Diameter ≥ 4.5m; capacity ≥ 100m3 ;

Can be designed and customized according to customers' requirements.

◣ Product Standards

HG/T 20696-2018 Technical Code of Reinforced Plastics equipment for Chemical Industry

HG/T 3983-2007 Filament Wound Glass-fiber Reinforced Thermosetting Resin Chemical Resistant Large Tanks Made On Site

◣ Product Characteristics
● Corrosion resistance, long service life;

● Light weight, convenient construction and installation;

● Low thermal conductivity, good thermal insulation performance.

◣ Application

Petroleum, chemical, medicine, food brewing, etc..

◣ Parameter

Volume	Diameter	Wall height
m3	m	m
100	5.0	5.6
200	6.5	6.5
300	7.5	7.5
400	8.0	8.7
500	9.0	8.7
700	10.0	9.5
1000	11.0	11.0
1000	11.5	10.5
1500	15.0	8.9
2000	16.0	11.0
3000	19.0	11.7
5000	23.6	12.5

Note: the above specification parameters are for reference only, and can be customized according to customer's requirements.

◣ Enterprise Strength

Shengli Xinda New Material Co., Ltd. (hereinafter referred to as "Shengli Xinda Company") is a high-tech enterprise in the field of new materials, involving two major industries: composite material industry and anti-corrosion industry. Its markets are found in PetroChina, Sinopec, municipal field, military industry, coalbed methane, electricity, marine, rail transit, spaceflight etc..

◣ Enterprise ualification

Shengli Xinda Company is the top three comprehensive strength enterprise of composite material published by CCIA, the champion of composite material pipes accredited by the Ministry of Industry and Information Technology of the People's Republic of China, the National Intellectual Property Demonstration Enterprise and is one of the winners of the 5th Dongying mayor quality award. Shengli Xinda Company has CNAS national accredited laboratory and many provincial technology R&D platforms such as provincial demonstration engineering technology research center, engineering technology center, enterprise technology center and post-doctoral innovation practice base. In recent years, the company has not only undertaken 6 national-level science and technology projects, more than 60 provincial-level and Sinopec-level science and technology projects, and more than 50 city-level and Shengli Oilfield-level science and technology projects, but also dominated and participated in compiling 9 national-level technical standards. The company is an AA level enterprise of credit audit rating from Commercial Credit Center, a trustworthy enterprise with standardized good behavior of Shandong Province. The company has passed API certification of American Petroleum Institute, GJB certification, ISO, CCS certification. “Xinda” trademark is the national famous trademark.
